Innolux MT190AW02 V.Y idatadata, iinkcukacha, izitokhwe, usetyenziso www.looklcd-xh.com
LookLCD LookLCD


MT190AW02 V.Y

MT190AW02 V.Y
MT190AW02 V.Y
MT190AW02 V.Y
MT190AW02 V.Y thumb MT190AW02 V.Y thumb MT190AW02 V.Y thumb
Uphawu
Innolux
Ubungakanani
19.0
Isicelo
DMPC
Isigqibo
1440×900
Ukuqamba
LCM
Ukuqaqamba
300
CR
1000:1
Imibala
16.7M
Isibane ngasemva
CCFL
Ujongano
LVDS
In Stock
40
Iinkcukacha

Inombolo yendawo MT190AW02 V.Y
UphawuInnolux
Ubungakanani19.0
IsiceloDMPC
Isigqibo1440×900
UkuqambaLCM
Ukuqaqamba300
CR1000:1
Imibala16.7M
Isibane ngasemvaCCFL
UjonganoLVDS
uphawu lwephaneliINNOLUX
imodeli yephaneliMT190AW02 V.Y
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli19.0 inch
isisombululo1440(RGB)×900 , WXGA+
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo408.24×255.15 mm
ulwandlalo428×278×16.5 mm
umphezuluAntiglare (Haze 25%), Hard coating (3H)
ukuqaqamba300 cd/m² (Typ.)
umlinganiselo wokuchasana1000:1 (Typ.)
bonisa imibala16.7M (6-bit + Hi-FRC), CIE193172%
ixesha lokuphendula1.5/3.5 (Typ.)(Tr/Td)
i-engile yokujonga85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibane4 pcsCCFLWithout Driver
ujongano lomqondisoLVDS (2 ch, 8-bit), 30 pins
igalelo lombane5.0V (Typ.)
isiceloDMPC
Umzekelo woSapho
LM190E08-TLL1 LG Display 19.0 1280×1024
MT190AW01 V.5 Innolux 19.0 1440×900
MT190AW01 V.7 Innolux 19.0 1440×900
MT190AW01 V.C Innolux 19.0 1440×900
MT190AW02 V.0 Innolux 19.0 1440×900
MT190AW02 V.4 Innolux 19.0 1440×900
MT190AW02 V.A Innolux 19.0 1440×900
MT190AW02 V.V Innolux 19.0 1440×900
MT190AW02 V.W Innolux 19.0 1440×900
MT190AW02 V.Y Innolux 19.0 1440×900
