AUO M240HTN01.1 idatadata, iinkcukacha, izitokhwe, usetyenziso www.looklcd-xh.com
LookLCD LookLCD


M240HTN01.1

M240HTN01.1
M240HTN01.1
M240HTN01.1
M240HTN01.1 thumb M240HTN01.1 thumb M240HTN01.1 thumb
Uphawu
AUO
Ubungakanani
24.0
Isicelo
DMPC
Isigqibo
1920×1080
Ukuqamba
LCM
Ukuqaqamba
200
CR
600:1
Imibala
16.7M
Isibane ngasemva
WLED
Ujongano
LVDS
In Stock
24
Iinkcukacha

Inombolo yendawo M240HTN01.1
UphawuAUO
Ubungakanani24.0
IsiceloDMPC
Isigqibo1920×1080
UkuqambaLCM
Ukuqaqamba200
CR600:1
Imibala16.7M
Isibane ngasemvaWLED
UjonganoLVDS
uphawu lwephaneliAUO
imodeli yephaneliM240HTN01.1
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli24.0 inch
isisombululo1920(RGB)×1080 , FHD
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo531.36×298.89 mm
ulwandlalo556×323.2×12 mm
umphezuluAntiglare, Hard coating (3H)
ukuqaqamba200 cd/m² (Typ.)
umlinganiselo wokuchasana600:1 (Typ.)
bonisa imibala16.7M (6-bit + Hi-FRC)
ixesha lokuphendula3.5/1.5 (Typ.)(Tr/Td)
i-engile yokujonga45/45/20/45 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibane8S4PWLEDWithout Driver
ujongano lomqondisoLVDS (2 ch, 8-bit), 30 pins
igalelo lombane5.0V (Typ.)
isiceloDMPC
Umzekelo woSapho
M240HTD01.0 AUO 24.0 1920×1080
M240HTN01.2 AUO 24.0 1920×1080
M240HVN02.0 AUO 24.0 1920×1080
M240HW01 V2 AUO 24.0 1920×1080
M240HW01 V8 AUO 24.0 1920×1080
M240HW01 VB AUO 24.0 1920×1080
M240HW01 VC AUO 24.0 1920×1080
M240HW02 V1 AUO 24.0 1920×1080
M240HW02 V6 AUO 24.0 1920×1080
M240HW02 V7 AUO 24.0 1920×1080
