MT190AW01 V.C

MT190AW01 V.C
MT190AW01 V.C
MT190AW01 V.C
MT190AW01 V.C thumb MT190AW01 V.C thumb MT190AW01 V.C thumb
Uphawu
Innolux
Ubungakanani
19.0
Isicelo
DMPC
Isigqibo
1440×900
Ukuqamba
LCM
Ukuqaqamba
250
CR
1000:1
Imibala
16.2M
Isibane ngasemva
CCFL
Ujongano
LVDS
In Stock
7798
Iinkcukacha

Inombolo yendawo MT190AW01 V.C
UphawuInnolux
Ubungakanani19.0
IsiceloDMPC
Isigqibo1440×900
UkuqambaLCM
Ukuqaqamba250
CR1000:1
Imibala16.2M
Isibane ngasemvaCCFL
UjonganoLVDS
uphawu lwephaneliINNOLUX
imodeli yephaneliMT190AW01 V.C
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli19.0 inch
isisombululo1440(RGB)×900 , WXGA+
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo410.4×256.5 mm
ulwandlalo427.2×277.4×16.5 mm
umphezuluAntiglare (Haze 25%), Hard coating (3H)
ukuqaqamba250 cd/m² (Typ.)
umlinganiselo wokuchasana1000:1 (Typ.)
bonisa imibala16.2M (6-bit + FRC)
ixesha lokuphendula1.5/3.5 (Typ.)(Tr/Td)
i-engile yokujonga80/80/80/80 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibane4 pcsCCFLWithout Driver
ujongano lomqondisoLVDS (2 ch, 8-bit), 30 pins
igalelo lombane5.0V (Typ.)
isiceloDMPC
