N080ICE-GB0 Rev.A1

N080ICE-GB0 Rev.A1
N080ICE-GB0 Rev.A1
N080ICE-GB0 Rev.A1 thumb N080ICE-GB0 Rev.A1 thumb
Uphawu
Innolux
Ubungakanani
8.0
Isicelo
PAD
Isigqibo
800×1280
Ukuqamba
LCM
Ukuqaqamba
400
CR
800:1
Imibala
16.7M
Isibane ngasemva
WLED
Ujongano
MIPI
In Stock
1720
Iinkcukacha

Inombolo yendawo N080ICE-GB0 Rev.A1
UphawuInnolux
Ubungakanani8.0
IsiceloPAD
Isigqibo800×1280
UkuqambaLCM
Ukuqaqamba400
CR800:1
Imibala16.7M
Isibane ngasemvaWLED
UjonganoMIPI
uphawu lwephaneliINNOLUX
imodeli yephaneliN080ICE-GB0 Rev.A1
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli8.0 inch
isisombululo800(RGB)×1280 , WXGA
imowudi yokubonisaAAS, Normally Black, Transmissive
indawo esebenzayo107.64×172.224 mm
ulwandlalo114.58×184.09×4.06 mm
umphezuluHard coating, Antireflection
ukuqaqamba400 cd/m² (Typ.)
umlinganiselo wokuchasana800:1 (Typ.)
bonisa imibala16.7M (8-bit), CIE193160%
ixesha lokuphendula20 (Typ.)(Tr+Td)
i-engile yokujonga89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibane4 stringsWLEDWithout Driver
ujongano lomqondisoMIPI (4 data lanes), 31 pins
igalelo lombane1.8/3.3V (Typ.)(VDDI/VCI)
isiceloPAD
Umzekelo woSapho
A080SN03 V2 AUO 8.0 800×600
CLAA080NA01 CW CPT 8.0 1024×600
HJ080IA-01B Innolux 8.0 1024×768
N080ICE-GB0 Rev.A0 Innolux 8.0 800×1280
N080ICE-GB0 Rev.A1 Innolux 8.0 800×1280
N080ICE-GB0 Rev.B1 Innolux 8.0 800×1280
N080ICE-GB0 Rev.C1 Innolux 8.0 800×1280
N080ICE-GB0 Rev.C2 Innolux 8.0 800×1280
N080ICE-GB1 Innolux 8.0 800×1280
TX20D28VM2BAB KOE 8.0 800×480
