Innolux HJ080IA-01B idatadata, iinkcukacha, izitokhwe, usetyenziso www.looklcd-xh.com

HJ080IA-01B


Uphawu
Innolux
Ubungakanani
8.0
Isicelo
PAD
Isigqibo
1024×768
Ukuqamba
LCM
Ukuqaqamba
350
CR
800:1
Imibala
262K/16.7M
Isibane ngasemva
WLED
Ujongano
LVDS
In Stock
17733
Iinkcukacha

Inombolo yendawo HJ080IA-01B
UphawuInnolux
Ubungakanani8.0
IsiceloPAD
Isigqibo1024×768
UkuqambaLCM
Ukuqaqamba350
CR800:1
Imibala262K/16.7M
Isibane ngasemvaWLED
UjonganoLVDS
uphawu lwephaneliCHIMEI INNOLUX
imodeli yephaneliHJ080IA-01B
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli8.0 inch
isisombululo1024(RGB)×768 , XGA
imowudi yokubonisaIPS, Normally Black, Transmissive
indawo esebenzayo162.048×121.536 mm
ulwandlalo174×136×2.9 mm
umphezuluHard coating
ukuqaqamba350 cd/m² (Typ.)
umlinganiselo wokuchasana800:1 (Typ.)
bonisa imibala262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150%
ixesha lokuphendula25 (Typ.)(Tr+Td)
i-engile yokujonga85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibane3S11PWLEDWithout Driver
ujongano lomqondisoLVDS (1 ch, 6/8-bit), 40 pins
igalelo lombane3.3/10.0/18.9/-7.8V (Typ.)(VCC/AVDD/VGH/VGL)
isiceloPAD
