Innolux N080ICE-GB0 Rev.A0 idatadata, iinkcukacha, izitokhwe, usetyenziso www.looklcd-xh.com

N080ICE-GB0 Rev.A0


Uphawu
Innolux
Ubungakanani
8.0
Isicelo
PAD
Isigqibo
800×1280
Ukuqamba
LCM
Ukuqaqamba
400
CR
1000:1
Imibala
16.7M
Isibane ngasemva
WLED
Ujongano
MIPI
In Stock
38688
Iinkcukacha

Inombolo yendawo N080ICE-GB0 Rev.A0
UphawuInnolux
Ubungakanani8.0
IsiceloPAD
Isigqibo800×1280
UkuqambaLCM
Ukuqaqamba400
CR1000:1
Imibala16.7M
Isibane ngasemvaWLED
UjonganoMIPI
uphawu lwephaneliINNOLUX
imodeli yephaneliN080ICE-GB0 Rev.A0
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli8.0 inch
isisombululo800(RGB)×1280 , WXGA
imowudi yokubonisaAAS, Normally Black, Transmissive
indawo esebenzayo107.64×172.224 mm
ulwandlalo114.6×184.1×3.5 mm
umphezuluGlare (Haze 0%), Hard coating, Antireflection
ukuqaqamba400 cd/m² (Typ.)
umlinganiselo wokuchasana1000:1 (Typ.)
bonisa imibala16.7M (8-bit), CIE193160%
ixesha lokuphendula25 (Typ.)(Tr+Td)
i-engile yokujonga89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibaneWLEDWithout Driver
ujongano lomqondisoMIPI (4 data lanes), 39 pins
igalelo lombane1.8/3.3V (Typ.)(VCC/VDDI)
isiceloPAD
