M215HGJ-P02

M215HGJ-P02
M215HGJ-P02
M215HGJ-P02 thumb M215HGJ-P02 thumb
Uphawu
Innolux
Ubungakanani
21.5
Isicelo
DMPC
Isigqibo
1920×1080
Ukuqamba
CELL
Ukuqaqamba
0
CR
1000:1
Imibala
16.7M
Isibane ngasemva
No B/L
Ujongano
LVDS
In Stock
1500
Iinkcukacha

Inombolo yendawo M215HGJ-P02
UphawuInnolux
Ubungakanani21.5
IsiceloDMPC
Isigqibo1920×1080
UkuqambaCELL
Ukuqaqamba0
CR1000:1
Imibala16.7M
Isibane ngasemvaNo B/L
UjonganoLVDS
uphawu lwephaneliCHIMEI INNOLUX
imodeli yephaneliM215HGJ-P02
uhlobo lwephaneli a-Si TFT-LCD , CELL
ubungakanani bephaneli21.5 inch
isisombululo1920(RGB)×1080 , FHD
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo476.64×268.11 mm
ulwandlalo487.14×280.41 mm
umphezuluAntiglare (Haze 25%), Hard coating (3H)
ubunzulu beglasi0.50+0.50 mm
transmissivity6.1% (Typ.)(with Polarizer)
umlinganiselo wokuchasana1000:1 (Typ.)
bonisa imibala16.7M (6-bit + Hi-FRC)
ixesha lokuphendula1.5/3.5 (Typ.)(Tr/Td)
i-engile yokujonga85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
ujongano lomqondisoLVDS (2 ch, 8-bit), 30 pins
igalelo lombane5.0V (Typ.)
isiceloDMPC
