AUO M170EG02 V3 idatadata, iinkcukacha, izitokhwe, usetyenziso www.looklcd-xh.com
LookLCD LookLCD


M170EG02 V3

M170EG02 V3
M170EG02 V3
M170EG02 V3
M170EG02 V3 thumb M170EG02 V3 thumb M170EG02 V3 thumb
Uphawu
AUO
Ubungakanani
17.0
Isicelo
DMPC
Isigqibo
1280×1024
Ukuqamba
LCM
Ukuqaqamba
300
CR
600:1
Imibala
16.2M
Isibane ngasemva
CCFL
Ujongano
LVDS
In Stock
10421
Iinkcukacha

Inombolo yendawo M170EG02 V3
UphawuAUO
Ubungakanani17.0
IsiceloDMPC
Isigqibo1280×1024
UkuqambaLCM
Ukuqaqamba300
CR600:1
Imibala16.2M
Isibane ngasemvaCCFL
UjonganoLVDS
uphawu lwephaneliAUO
imodeli yephaneliM170EG02 V3 1 Compatible model
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli17.0 inch
isisombululo1280(RGB)×1024 , SXGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo337.92×270.336 mm
ulwandlalo358.5×296.6×15 mm
umphezuluAntiglare, Hard coating (3H)
ukuqaqamba300 cd/m² (Typ.)
umlinganiselo wokuchasana600:1 (Typ.)
bonisa imibala16.2M (6-bit + FRC)
ixesha lokuphendula2/6 (Typ.)(Tr/Td)
i-engile yokujonga70/70/65/60 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibane4 pcsCCFLWithout Driver
ujongano lomqondisoLVDS (2 ch, 8-bit), 30 pins
igalelo lombane5.0V (Typ.)
isiceloDMPC
Umzekelo woSapho
M170E5-L08 Innolux 17.0 1280×1024
M170E8-L01 Innolux 17.0 1280×1024
M170EG01 V0 AUO 17.0 1280×1024
M170EG01 V5 AUO 17.0 1280×1024
M170EG01 VA AUO 17.0 1280×1024
M170EG01 VD AUO 17.0 1280×1024
M170EG01 VF AUO 17.0 1280×1024
M170EG01 VH AUO 17.0 1280×1024
M170EP01 V0 AUO 17.0 1280×1024
M170EU01 V0 AUO 17.0 1280×1024
