AT070TN92 V.3

AT070TN92 V.3
AT070TN92 V.3
AT070TN92 V.3
AT070TN92 V.3 thumb AT070TN92 V.3 thumb AT070TN92 V.3 thumb
Uphawu
Innolux
Ubungakanani
7.0
Isicelo
MP4
Isigqibo
800×480
Ukuqamba
LCM
Ukuqaqamba
250
CR
500:1
Imibala
262K/16.7M
Isibane ngasemva
WLED
Ujongano
TTL
In Stock
6457
Iinkcukacha

Inombolo yendawo AT070TN92 V.3
UphawuInnolux
Ubungakanani7.0
IsiceloMP4
Isigqibo800×480
UkuqambaLCM
Ukuqaqamba250
CR500:1
Imibala262K/16.7M
Isibane ngasemvaWLED
UjonganoTTL
uphawu lwephaneliCHIMEI INNOLUX
imodeli yephaneliAT070TN92 V.3
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli7.0 inch
isisombululo800(RGB)×480 , WVGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo154.08×85.92 mm
ulwandlalo164.9×100×3.65 mm
umphezuluAntiglare
ukuqaqamba250 cd/m² (Typ.)
umlinganiselo wokuchasana500:1 (Typ.)
bonisa imibala262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150%
ixesha lokuphendula10/15 (Typ.)(Tr/Td)
i-engile yokujonga70/70/50/70 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibane3S9PWLEDWithout Driver
ujongano lomqondisoParallel RGB (1 ch, 6/8-bit), 50 pins
igalelo lombane3.3/10.4/16.0/-7.0V (Typ.)(DVDD/AVDD/VGH/VGL)
isiceloMP4
