AT070TNA2 V.1

AT070TNA2 V.1
AT070TNA2 V.1
AT070TNA2 V.1 thumb AT070TNA2 V.1 thumb
Uphawu
Innolux
Ubungakanani
7.0
Isicelo
MP4
Isigqibo
1024×600
Ukuqamba
LCM
Ukuqaqamba
250
CR
700:1
Imibala
262K/16.7M
Isibane ngasemva
WLED
Ujongano
LVDS
In Stock
1000
Iinkcukacha

Inombolo yendawo AT070TNA2 V.1
UphawuInnolux
Ubungakanani7.0
IsiceloMP4
Isigqibo1024×600
UkuqambaLCM
Ukuqaqamba250
CR700:1
Imibala262K/16.7M
Isibane ngasemvaWLED
UjonganoLVDS
uphawu lwephaneliCHIMEI INNOLUX
imodeli yephaneliAT070TNA2 V.1 4 Compatible model
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli7.0 inch
isisombululo1024(RGB)×600 , WSVGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo153.6×90 mm
ulwandlalo165.75×105.39×3.7 mm
umphezuluGlare (Haze 0%), Hard coating
ukuqaqamba250 cd/m² (Typ.)
umlinganiselo wokuchasana700:1 (Typ.)
bonisa imibala262K/16.7M (6-bit / 6-bit + Dithering)
ixesha lokuphendula10/15 (Typ.)(Tr/Td)
i-engile yokujonga75/75/70/75 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibane3S6PWLEDWithout Driver
ujongano lomqondisoLVDS (1 ch, 6/8-bit), 40 pins
igalelo lombane3.3/11.0/20.0/-6.8V (Typ.)(VDD/AVDD/VGH/VGL)
isiceloMP4
Umzekelo woSapho
AT070TN07 V.A Innolux 7.0 480×234
AT070TN82 Innolux 7.0 800×480
AT070TN82 V.1 Innolux 7.0 800×480
AT070TN83 V.3 Innolux 7.0 800×480
AT070TN84 Innolux 7.0 800×480
AT070TN84 V.1 Innolux 7.0 800×480
AT070TN90 Innolux 7.0 800×480
AT070TN92 V.3 Innolux 7.0 800×480
AT070TN93 Innolux 7.0 800×480
AT070TNA2 Innolux 7.0 1024×600
