Innolux AT070TN07 V.D idatadata, iinkcukacha, izitokhwe, usetyenziso www.looklcd-xh.com
LookLCD LookLCD


AT070TN07 V.D

AT070TN07 V.D
AT070TN07 V.D
AT070TN07 V.D thumb AT070TN07 V.D thumb
Uphawu
Innolux
Ubungakanani
7.0
Isicelo
VDP
Isigqibo
480×234
Ukuqamba
LCM
Ukuqaqamba
200
CR
300:1
Imibala
Full color
Isibane ngasemva
WLED
Ujongano
Analog
In Stock
4500
Iinkcukacha

Inombolo yendawo AT070TN07 V.D
UphawuInnolux
Ubungakanani7.0
IsiceloVDP
Isigqibo480×234
UkuqambaLCM
Ukuqaqamba200
CR300:1
ImibalaFull color
Isibane ngasemvaWLED
UjonganoAnalog
uphawu lwephaneliINNOLUX
imodeli yephaneliAT070TN07 V.D
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli7.0 inch
isisombululo480(RGB)×234
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo154.08×86.58 mm
ulwandlalo164.9×100 mm
umphezuluAntiglare
ukuqaqamba200 cd/m² (Typ.)
umlinganiselo wokuchasana300:1 (Typ.)
bonisa imibalaFull color
ixesha lokuphendula15/20 (Typ.)(Tr/Td)
i-engile yokujonga60/60/40/60 (Typ.)(CR≥10)(L/R/U/D)
uhlobo lwesibane3S4PWLEDWithout Driver
ujongano lomqondisoTFT Specific Analog RGB, 26 pins
igalelo lombane(3.3/5.0)/5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL)
rohs:
isiceloVDP
