| Inombolo yendawo | AM-1024600Y3TZQW-A0H |
| Uphawu | AMPIRE |
| Ubungakanani | 9.0 |
| Isicelo | Industrial |
| Isigqibo | 1024×600 |
| Ukuqamba | a-Si TFT-LCD, LCM |
| Ukuqaqamba | |
| CR | 800:1 |
| Imibala | 16.7M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| uphawu lwephaneli | AMPIRE |
| imodeli yephaneli | AM-1024600Y3TZQW-A0H |
| ubungakanani bephaneli | 9.0" |
| uhlobo lwephaneli | a-Si TFT-LCD, LCM |
| isisombululo | 1024(RGB)×600, WSVGA, 132PPI |
| ifomathi ye-pixel | RGB Vertical Stripe |
| indawo yokubonisa | 196.6(W)×114.1(H) mm |
| ukuvulwa kwe-bezel | 200(W)×117.55(H) mm |
| ubungakanani bamagqabantshintshi | 211.1(W)×126.5(H) ×11(D) mm |
| umphezulu | - |
| ukuqaqamba | 500 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 800:1 (Typ.) (TM) |
| i-engile yokujonga | 85/85/85/85 (Typ.)(CR≥10) |
| imowudi yokubonisa | Normally Black, Transmissive |
| eyona mbono kwi | Symmetry |
| ixesha lokuphendula | 18/17 (Typ.)(Tr/Td) |
| bonisa imibala | 16.7M |
| uhlobo lwesibane | WLED , With LED Driver |
| rhoqo | 60Hz |
| isikrini esibanjwayo | Without |
| Ubunzima bephaneli | TBD |
| isicelo | Industrial |
| ujongano lomqondiso | LVDS (1 ch, 8-bit) , 30 pins Connector |
| igalelo lombane | 3.3V (Typ.) |
| okusingqongileyo | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
