| Inombolo yendawo | TM090JDH01 |
| Uphawu | Tianma |
| Ubungakanani | 9.0 |
| Isicelo | PAD |
| Isigqibo | 1280×800 |
| Ukuqamba | LCM |
| Ukuqaqamba | 250 |
| CR | 700:1 |
| Imibala | 262K/16.7M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| uphawu lwephaneli | TIANMA |
| imodeli yephaneli | TM090JDH01 1 Compatible model |
| uhlobo lwephaneli | a-Si TFT-LCD , LCM |
| ubungakanani bephaneli | 9.0 inch |
| isisombululo | 1280(RGB)×800 , WXGA |
| imowudi yokubonisa | TN, Normally White, Transmissive |
| indawo esebenzayo | 193.92×121.2 mm |
| ulwandlalo | 206.76×135.06×4.8 mm |
| umphezulu | |
| ukuqaqamba | 250 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 700:1 (Typ.) |
| bonisa imibala | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193170% |
| ixesha lokuphendula | 25 (Typ.)(Tr+Td) |
| i-engile yokujonga | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| rhoqo | 60Hz |
| uhlobo lwesibane | 3S12PWLEDWithout Driver |
| ujongano lomqondiso | LVDS (1 ch, 6/8-bit), 51 pins |
| igalelo lombane | 3.3/11/20/-6.8V (Typ.)(VCC/AVDD/VGH/VGL) |
| isicelo | PAD |
| AA090ME01 | Mitsubishi | 9.0 | 800×480 |
| AT090TN23 | Innolux | 9.0 | 1280×800 |
| C090EAN01.1 | AUO | 9.0 | 1280×720 |
| G090VTN02.0 | AUO | 9.0 | 800×480 |
| HSD090ICW1-A00 | HannStar | 9.0 | 640×234 |
| HSD090IDW1-A00 | HannStar | 9.0 | 800×480 |
| LQ090Y3DG01 | SHARP | 9.0 | 800×480 |
| LQ090Y3DG01A | SHARP | 9.0 | 800×480 |
| TM090JDH01 | Tianma | 9.0 | 1280×800 |
| YX090DKN01.0 | SEBO | 9.0 | 1280×720 |
| B080XAN01.0 | AUO | 7.9 | 768×1024 |
| B101UAN01.9 | AUO | 10.1 | 1920×1200 |
| B101UAN07.2 | AUO | 10.1 | 1200×1920 |
| HJ101IA-01F | Innolux | 10.1 | 1280×800 |
| HSD100PXN1-A00 | HannStar | 10.0 | 1024×768 |
| HV070WS1-105 | HYDIS | 7.0 | 1024×600 |
| LP079X01-SMA7 | LG Display | 7.9 | 768×1024 |
| LQ097L1JY01A | SHARP | 9.7 | 2048×1536 |
| LQ101K1LY02 | SHARP | 10.1 | 1280×800 |
| LTL089CL02-001 | Samsung | 8.9 | 1920×1200 |
