| Inombolo yendawo | AT090TN23 |
| Uphawu | Innolux |
| Ubungakanani | 9.0 |
| Isicelo | PAD |
| Isigqibo | 1280×800 |
| Ukuqamba | LCM |
| Ukuqaqamba | 340 |
| CR | 700:1 |
| Imibala | 262K/16.7M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| uphawu lwephaneli | CHIMEI INNOLUX |
| imodeli yephaneli | AT090TN23 |
| uhlobo lwephaneli | a-Si TFT-LCD , LCM |
| ubungakanani bephaneli | 9.0 inch |
| isisombululo | 1280(RGB)×800 , WXGA |
| imowudi yokubonisa | TN, Normally White, Transmissive |
| indawo esebenzayo | 193.92×121.2 mm |
| ulwandlalo | 206.76×135.06 mm |
| umphezulu | |
| ukuqaqamba | 340 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 700:1 (Typ.) |
| bonisa imibala | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193170% |
| ixesha lokuphendula | 10/15 (Typ.)(Tr/Td) |
| i-engile yokujonga | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| rhoqo | 60Hz |
| uhlobo lwesibane | WLEDWithout Driver |
| ujongano lomqondiso | LVDS (1 ch, 6/8-bit), 40 pins |
| igalelo lombane | 3.3/11.0/20.0/-6.8V (Typ.)(DVDD/AVDD/VGH/VHL) |
| isicelo | PAD |
