| Inombolo yendawo | S035LQNC111 |
| Uphawu | CDTECH |
| Ubungakanani | 3.5 |
| Isicelo | Automotive Display I |
| Isigqibo | 320×240 |
| Ukuqamba | a-Si TFT-LCD , LCM |
| Ukuqaqamba | |
| CR | 350:1 |
| Imibala | 16.7M |
| Isibane ngasemva | WLED |
| Ujongano | Parallel |
| uphawu | CDTECH |
| ubungakanani bediagonal | 3.5 inch |
| ifomathi ye-pixel | 320(RGB)×240 [QVGA] 115PPI |
| indawo esebenzayo | 70.08(H)×52.56(V) mm |
| indawo ye-bezel | 71.3(H)×55.5(V) mm |
| ukukhanya | 350 cd/m² (Typ.) |
| Jonga indlela | 12 o'clock |
| i-engile yokujonga | 65/65/65/55 (Typ.)(CR≥10) |
| umbala inkxaso | 16.7M 50% NTSC |
| ubunzima | TBD |
| umgangatho wefreyimu | 60Hz |
| uhlobo lojongano | Parallel RGB (1 ch, 8-bit) + SPI , 54 pins FPC |
| ukunikezwa Amandla | 3.3V (Typ.) |
| okusingqongileyo | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| imodeli | S035LQNC111 2 Compatible |
| uhlobo | a-Si TFT-LCD , LCM |
| uqwalaselo | RGB Vertical Stripe |
| ulwandlalo mfiliba. | 76.9(H)×63.9(V) ×3.46(D) mm |
| unyango | Hard coating |
| umlinganiselo wokuchasana | 350:1 (Typ.) (TM) |
| ixesha lokuphendula | 25/25 (Typ.)(Tr/Td) |
| indlela yokusebenza | TN, Normally White, Transmissive |
| umthombo wokukhanya | WLED [6S1P] , 25K hours , W/O Driver |
| yenzelwe | Automotive Display Industrial Handheld & PDA |
| indawo yokuthintela | Without |
