Inombolo yendawo | NL8060BC31-42D |
Uphawu | NLT |
Ubungakanani | 12.1 |
Isicelo | IA |
Isigqibo | 800×600 |
Ukuqamba | LCM |
Ukuqaqamba | 400 |
CR | 600:1 |
Imibala | 262K |
Isibane ngasemva | CCFL |
Ujongano | TTL |
uphawu lwephaneli | NEC |
imodeli yephaneli | NL8060BC31-42D |
uhlobo lwephaneli | a-Si TFT-LCD , LCM |
ubungakanani bephaneli | 12.1 inch |
isisombululo | 800(RGB)×600 , SVGA |
imowudi yokubonisa | TN, Normally White, Transmissive |
indawo esebenzayo | 246×184.5 mm |
ulwandlalo | 280×210×11.5 mm |
umphezulu | Antiglare, Hard coating (3H) |
ukuqaqamba | 400 cd/m² (Typ.) |
umlinganiselo wokuchasana | 600:1 (Typ.) |
bonisa imibala | 262K (6-bit), CIE193140% |
ixesha lokuphendula | 6/19 (Typ.)(Tr/Td) |
i-engile yokujonga | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
rhoqo | 60Hz |
uhlobo lwesibane | 2 pcsCCFLWithout Driver |
ujongano lomqondiso | CMOS (1 ch, 6-bit), 41 pins |
igalelo lombane | 3.3/5.0V (Typ.)(VCC) |
isicelo | IA |
