NLT NL6448AC33-15 idatadata, iinkcukacha, izitokhwe, usetyenziso www.looklcd-xh.com

NL6448AC33-15


Uphawu
NLT
Ubungakanani
10.4
Isicelo
IA
Isigqibo
640×480
Ukuqamba
LCM
Ukuqaqamba
200
CR
150:1
Imibala
Full color
Isibane ngasemva
CCFL
Ujongano
Analog
In Stock
95
Iinkcukacha

Inombolo yendawo NL6448AC33-15
UphawuNLT
Ubungakanani10.4
IsiceloIA
Isigqibo640×480
UkuqambaLCM
Ukuqaqamba200
CR150:1
ImibalaFull color
Isibane ngasemvaCCFL
UjonganoAnalog
uphawu lwephaneliNEC
imodeli yephaneliNL6448AC33-15
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli10.4 inch
isisombululo640(RGB)×480 , VGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo211.2×158.4 mm
ulwandlalo251×196×24 mm
umphezulu
ukuqaqamba200 cd/m² (Typ.)
umlinganiselo wokuchasana150:1 (Typ.)
bonisa imibalaFull color , CIE193155%
ixesha lokuphendula40 (Max.)(Tr)
i-engile yokujonga50/50/15/45 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibane2 pcsCCFLEmbedded (Inverter)
ujongano lomqondisoAnalog RGB, 23 pins
igalelo lombane5.0/12.0V (Typ.)(VCC/VDD1)
isiceloIA
Umzekelo woSapho
NL6448AC30-09 NLT 9.4 640×480
NL6448AC33-18A NLT 10.4 640×480
NL6448AC33-24 NLT 10.4 640×480
NL6448AC33-29 NLT 10.4 640×480
NL6448BC18-01F NLT 5.7 640×480
NL6448BC26-01 NLT 8.4 640×480
NL6448BC26-15 NLT 8.4 640×480
NL6448BC33-21 NLT 10.4 640×480
NL6448BC33-54 NLT 10.4 640×480
NL6448BC33-64E NLT 10.4 640×480
