Inombolo yendawo | NL6448BC26-15 |
Uphawu | NLT |
Ubungakanani | 8.4 |
Isicelo | IA |
Isigqibo | 640×480 |
Ukuqamba | LCM |
Ukuqaqamba | 450 |
CR | 600:1 |
Imibala | 262K/16.7M |
Isibane ngasemva | CCFL |
Ujongano | LVDS |
uphawu lwephaneli | NEC |
imodeli yephaneli | NL6448BC26-15 |
uhlobo lwephaneli | a-Si TFT-LCD , LCM |
ubungakanani bephaneli | 8.4 inch |
isisombululo | 640(RGB)×480 , VGA |
imowudi yokubonisa | TN, Normally White, Transmissive |
indawo esebenzayo | 170.88×128.16 mm |
ulwandlalo | 200×152 mm |
umphezulu | Clear, Hard coating (3H) |
ukuqaqamba | 450 cd/m² (Typ.) |
umlinganiselo wokuchasana | 600:1 (Typ.) |
bonisa imibala | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193140% |
ixesha lokuphendula | 6/19 (Typ.)(Tr/Td) |
i-engile yokujonga | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
rhoqo | 60Hz |
uhlobo lwesibane | 2 pcsCCFLWithout Driver |
ujongano lomqondiso | LVDS (1 ch, 6/8-bit), 20 pins |
igalelo lombane | 3.3V (Typ.) |
isicelo | IA |
