Inombolo yendawo | N156BGE-LB1 |
Uphawu | Innolux |
Ubungakanani | 15.6 |
Isicelo | NBPC |
Isigqibo | 1366×768 |
Ukuqamba | LCM |
Ukuqaqamba | 200 |
CR | 600:1 |
Imibala | 262K |
Isibane ngasemva | WLED |
Ujongano | LVDS |
uphawu lwephaneli | CHIMEI INNOLUX |
imodeli yephaneli | N156BGE-LB1 5 Compatible model |
uhlobo lwephaneli | a-Si TFT-LCD , LCM |
ubungakanani bephaneli | 15.6 inch |
isisombululo | 1366(RGB)×768 , WXGA |
imowudi yokubonisa | TN, Normally White, Transmissive |
indawo esebenzayo | 344.232×193.536 mm |
ulwandlalo | 359.5×223.8×3.2 mm |
isitayile semilo | Slim (PCBA Flat, Depth ≤3.2mm) |
umphezulu | Glare (Haze 0%), Hard coating (3H) |
ukuqaqamba | 200 cd/m² (Typ.) |
umlinganiselo wokuchasana | 600:1 (Typ.) |
bonisa imibala | 262K (6-bit), CIE193145% |
ixesha lokuphendula | 3/8 (Typ.)(Tr/Td) |
i-engile yokujonga | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
rhoqo | 60Hz |
uhlobo lwesibane | 11S3PWLEDEmbedded (LED Driver) |
ujongano lomqondiso | LVDS (1 ch, 6-bit), 40 pins |
igalelo lombane | 3.3V (Typ.) |
isicelo | NBPC |
N156B3-L02 | Innolux | 15.6 | 1366×768 |
N156B6-L01 | Innolux | 15.6 | 1366×768 |
N156B6-L0B | Innolux | 15.6 | 1366×768 |
N156B6-L3D | Innolux | 15.6 | 1366×768 |
N156BGE-E11 | Innolux | 15.6 | 1366×768 |
N156BGE-E41 | Innolux | 15.6 | 1366×768 |
N156BGE-EA1 | Innolux | 15.6 | 1366×768 |
N156BGE-L11 | Innolux | 15.6 | 1366×768 |
N156BGE-L62 | Innolux | 15.6 | 1366×768 |
N156BGE-LB1 | Innolux | 15.6 | 1366×768 |
B156HW01 V4 | AUO | 15.6 | 1920×1080 |
B156XTN02.0 | AUO | 15.6 | 1366×768 |
B156XTN02.4 | AUO | 15.6 | 1366×768 |
LTN140AT21-801 | Samsung | 14.0 | 1366×768 |
LTN141AT05-G03 | Samsung | 14.1 | 1280×800 |
LTN141BT04-001 | Samsung | 14.1 | 1440×900 |
LTN160AT06-B01 | Samsung | 16.0 | 1366×768 |
LTN173HT02-X01 | Samsung | 17.3 | 1920×1080 |
N133B6-L01 | Innolux | 13.3 | 1366×768 |
NL6448AC33-10 | NLT | 10.4 | 640×480 |
