M240HW01 V1

M240HW01 V1
M240HW01 V1
M240HW01 V1 thumb M240HW01 V1 thumb
Uphawu
AUO
Ubungakanani
24.0
Isicelo
DMPC
Isigqibo
1920×1080
Ukuqamba
LCM
Ukuqaqamba
250
CR
1000:1
Imibala
16.7M
Isibane ngasemva
WLED
Ujongano
LVDS
In Stock
14477
Iinkcukacha

Inombolo yendawo M240HW01 V1
UphawuAUO
Ubungakanani24.0
IsiceloDMPC
Isigqibo1920×1080
UkuqambaLCM
Ukuqaqamba250
CR1000:1
Imibala16.7M
Isibane ngasemvaWLED
UjonganoLVDS
uphawu lwephaneliAUO
imodeli yephaneliM240HW01 V1
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli24.0 inch
isisombululo1920(RGB)×1080 , FHD
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo531.36×298.89 mm
ulwandlalo556×323.2×15.05 mm
umphezuluAntiglare, Hard coating (3H)
ukuqaqamba250 cd/m² (Typ.)
umlinganiselo wokuchasana1000:1 (Typ.)
bonisa imibala16.7M (6-bit + Hi-FRC), CIE193172%
ixesha lokuphendula3.4/1.6 (Typ.)(Tr/Td); 2 (Typ.)(G to G)
i-engile yokujonga85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibaneWLEDWithout Driver
ujongano lomqondisoLVDS (2 ch, 8-bit), 30 pins
igalelo lombane5.0V (Typ.)
isiceloDMPC
Umzekelo woSapho
M240HTD01.0 AUO 24.0 1920×1080
M240HTN01.2 AUO 24.0 1920×1080
M240HVN01.0 AUO 24.0 1920×1080
M240HVN02.0 AUO 24.0 1920×1080
M240HW01 V0 AUO 24.0 1920×1080
M240HW01 V2 AUO 24.0 1920×1080
M240HW01 VB AUO 24.0 1920×1080
M240HW02 V1 AUO 24.0 1920×1080
M240HW02 V5 AUO 24.0 1920×1080
M240HW02 V6 AUO 24.0 1920×1080
