M190EG02 V4

M190EG02 V4
M190EG02 V4
M190EG02 V4 thumb M190EG02 V4 thumb
Uphawu
AUO
Ubungakanani
19.0
Isicelo
DMPC
Isigqibo
1280×1024
Ukuqamba
LCM
Ukuqaqamba
300
CR
800:1
Imibala
16.7M
Isibane ngasemva
CCFL
Ujongano
LVDS
In Stock
513
Iinkcukacha

Inombolo yendawo M190EG02 V4
UphawuAUO
Ubungakanani19.0
IsiceloDMPC
Isigqibo1280×1024
UkuqambaLCM
Ukuqaqamba300
CR800:1
Imibala16.7M
Isibane ngasemvaCCFL
UjonganoLVDS
uphawu lwephaneliAUO
imodeli yephaneliM190EG02 V4
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli19.0 inch
isisombululo1280(RGB)×1024 , SXGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo376.32×301.056 mm
ulwandlalo396×324×16.8 mm
umphezuluAntiglare, Hard coating (3H)
ukuqaqamba300 cd/m² (Typ.)
umlinganiselo wokuchasana800:1 (Typ.)
bonisa imibala16.7M (6-bit + Hi-FRC), CIE193172%
ixesha lokuphendula3.6/1.4 (Typ.)(Tr/Td); 5 (Typ.)(G to G)
i-engile yokujonga80/80/80/80 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibane4 pcsCCFLWithout Driver
ujongano lomqondisoLVDS (2 ch, 8-bit), 30 pins
igalelo lombane5.0V (Typ.)
isiceloDMPC
Umzekelo woSapho
M190E5-L0G Innolux 19.0 1280×1024
M190EG01 V0 AUO 19.0 1280×1024
M190EG01 V2 AUO 19.0 1280×1024
M190EG01 V3 AUO 19.0 1280×1024
M190EG02 V7 AUO 19.0 1280×1024
M190EN01 V1 AUO 19.0 1280×1024
M190EN03 V0 AUO 19.0 1280×1024
M190EN04 V1 AUO 19.0 1280×1024
M190EN04 V5 AUO 19.0 1280×1024
M190ETN01.0 AUO 19.0 1280×1024
