LG Display LP156WH2-TLB1 idatadata, iinkcukacha, izitokhwe, usetyenziso www.looklcd-xh.com

LP156WH2-TLB1


Uphawu
LG Display
Ubungakanani
15.6
Isicelo
NBPC
Isigqibo
1366×768
Ukuqamba
LCM
Ukuqaqamba
220
CR
400:1
Imibala
262K
Isibane ngasemva
WLED
Ujongano
LVDS
In Stock
16098
Iinkcukacha

Inombolo yendawo LP156WH2-TLB1
UphawuLG Display
Ubungakanani15.6
IsiceloNBPC
Isigqibo1366×768
UkuqambaLCM
Ukuqaqamba220
CR400:1
Imibala262K
Isibane ngasemvaWLED
UjonganoLVDS
uphawu lwephaneliLG Display
imodeli yephaneliLP156WH2-TLB1 61 Compatible model
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli15.6 inch
isisombululo1366(RGB)×768 , WXGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo344.232×193.536 mm
ulwandlalo359.3×209.5×5.5 mm
isitayile semiloWedge (PCBA Bent, Depth ≥5.2mm)
umphezuluAntiglare
ukuqaqamba220 cd/m² (Typ.)
umlinganiselo wokuchasana400:1 (Typ.)
bonisa imibala262K (6-bit)
ixesha lokuphendula15/25 (Typ.)(Tr/Td)
i-engile yokujonga45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibaneWLEDEmbedded (LED Driver)
ujongano lomqondisoLVDS (1 ch, 6-bit), 40 pins
igalelo lombane3.3V (Typ.)
isiceloNBPC
Umzekelo woSapho
LP156WD1-TPB1 LG Display 15.6 1600×900
LP156WF1-TLA1 LG Display 15.6 1920×1080
LP156WF3-SLB1 LG Display 15.6 1920×1080
LP156WF6-SPH3 LG Display 15.6 1920×1080
LP156WH2-TLC1 LG Display 15.6 1366×768
LP156WH2-TLD1 LG Display 15.6 1366×768
LP156WH2-TLR1 LG Display 15.6 1366×768
LP156WH3-TLE1 LG Display 15.6 1366×768
LP156WH4-TLB1 LG Display 15.6 1366×768
LP156WH4-TLN1 LG Display 15.6 1366×768
