LP156WD1-TLD3

LP156WD1-TLD3
LP156WD1-TLD3
LP156WD1-TLD3 thumb LP156WD1-TLD3 thumb
Uphawu
LG Display
Ubungakanani
15.6
Isicelo
NBPC
Isigqibo
1600×900
Ukuqamba
LCM
Ukuqaqamba
200
CR
300:1
Imibala
262K
Isibane ngasemva
WLED
Ujongano
LVDS
In Stock
100
Iinkcukacha

Inombolo yendawo LP156WD1-TLD3
UphawuLG Display
Ubungakanani15.6
IsiceloNBPC
Isigqibo1600×900
UkuqambaLCM
Ukuqaqamba200
CR300:1
Imibala262K
Isibane ngasemvaWLED
UjonganoLVDS
uphawu lwephaneliLG Display
imodeli yephaneliLP156WD1-TLD3 10 Compatible model
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli15.6 inch
isisombululo1600(RGB)×900 , HD+
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo344.16×193.59 mm
ulwandlalo359.3×209.5×5.7 mm
isitayile semiloWedge (PCBA Bent, Depth ≥5.2mm)
umphezuluAntiglare, Hard coating (3H)
ukuqaqamba200 cd/m² (Typ.)
umlinganiselo wokuchasana300:1 (Min.)
bonisa imibala262K (6-bit), CIE193160%
ixesha lokuphendula8 (Typ.)(Tr+Td)
i-engile yokujonga60/60/50/50 (Min.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibaneWLEDEmbedded (LED Driver)
ujongano lomqondisoLVDS (2 ch, 6-bit), 40 pins
igalelo lombane3.3V (Typ.)
isiceloNBPC
Umzekelo woSapho
LP156WD1-TLD5 LG Display 15.6 1600×900
LP156WF1-TLB1 LG Display 15.6 1920×1080
LP156WF3-SLB3 LG Display 15.6 1920×1080
LP156WF6-SPH3 LG Display 15.6 1920×1080
LP156WH1-TLC2 LG Display 15.6 1366×768
LP156WH2-TLE1 LG Display 15.6 1366×768
LP156WH4-TLN2 LG Display 15.6 1366×768
LP156WH4-TPA1 LG Display 15.6 1366×768
LP156WH8-TLA1 LG Display 15.6 1366×768
LP156WHB-TLA1 LG Display 15.6 1366×768
Imveliso eshushu
B133XTN01.6 HW1A AUO 13.3 1366×768
B140EW01 V5 AUO 14.0 1280×768
CLAA156WA07A CPT 15.6 1366×768
LP140WD1-TLM1 LG Display 14.0 1600×900
LP140WH8-TLA1 LG Display 14.0 1366×768
LP150X09-B2K3 LG Display 15.0 1024×768
LTD121LA3SG-201 TOSHIBA 12.1 1024×768
LTN133AT01-001 Samsung 13.3 1280×800
LTN156AT05-W01 Samsung 15.6 1366×768
VVX13F009G10 Panasonic 13.3 1920×1080
