B133XTN01.6 HW1A

B133XTN01.6 HW1A
B133XTN01.6 HW1A
B133XTN01.6 HW1A
B133XTN01.6 HW1A thumb B133XTN01.6 HW1A thumb B133XTN01.6 HW1A thumb
Uphawu
AUO
Ubungakanani
13.3
Isicelo
NBPC
Isigqibo
1366×768
Ukuqamba
LCM
Ukuqaqamba
220
CR
400:1
Imibala
262K
Isibane ngasemva
WLED
Ujongano
eDP
In Stock
800
Iinkcukacha

Inombolo yendawo B133XTN01.6 HW1A
UphawuAUO
Ubungakanani13.3
IsiceloNBPC
Isigqibo1366×768
UkuqambaLCM
Ukuqaqamba220
CR400:1
Imibala262K
Isibane ngasemvaWLED
UjonganoeDP
uphawu lwephaneliAUO
imodeli yephaneliB133XTN01.6 HW1A
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli13.3 inch
isisombululo1366(RGB)×768 , WXGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo293.42×164.97 mm
ulwandlalo314.1×188.7×3 mm
isitayile semiloSlim (PCBA Flat, Depth ≤3.2mm)
umphezuluAntiglare, Hard coating (3H), Reflection 4.3% (Typ.)
ukuqaqamba220 cd/m² (Typ.)
umlinganiselo wokuchasana400:1 (Typ.)
bonisa imibala262K (6-bit), CIE193145%
ixesha lokuphendula8 (Typ.)(Tr+Td)
i-engile yokujonga45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibaneWLEDEmbedded (LED Driver)
ujongano lomqondisoeDP (1 Lane), 30 pins
igalelo lombane3.3V (Typ.)
isiceloNBPC
Umzekelo woSapho
B133EW01 V0 AUO 13.3 1280×800
B133XTN01.0 AUO 13.3 1366×768
B133XTN01.2 AUO 13.3 1366×768
B133XTN01.5 AUO 13.3 1366×768
B133XTN01.6 HW0A AUO 13.3 1366×768
B133XTN01.6 HW1A AUO 13.3 1366×768
B133XTN02.1 AUO 13.3 1366×768
B133XW02 V0 AUO 13.3 1366×768
LP133WH2-TLN4 LG Display 13.3 1366×768
LTN133AT25-501 Samsung 13.3 1366×768
