| Inombolo yendawo | HSD101PUW1-E00 |
| Uphawu | HannStar |
| Ubungakanani | 10.1 |
| Isicelo | Pad & Tablet |
| Isigqibo | 1920×1200 |
| Ukuqamba | a-Si TFT-LCD , LCM |
| Ukuqaqamba | |
| CR | 1000:1 |
| Imibala | 16.7M |
| Isibane ngasemva | WLED |
| Ujongano | MIPI |
| uphawu | HannStar |
| ubungakanani bediagonal | 10.1 inch |
| ifomathi ye-pixel | 1920(RGB)×1200 [WUXGA] 225PPI |
| indawo esebenzayo | 216.576(H)×135.36(V) mm |
| ukukhanya | - |
| Jonga indlela | Symmetry |
| i-engile yokujonga | 89/89/89/89 (Typ.)(CR≥10) |
| umbala inkxaso | 16.7M 50% NTSC |
| ubunzima | - |
| umgangatho wefreyimu | 60Hz |
| uhlobo lojongano | MIPI (4 data lanes) , 39 pins Connector |
| ukunikezwa Amandla | 3.3V (Typ.) |
| okusingqongileyo | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| imodeli | HSD101PUW1-E00 |
| uhlobo | a-Si TFT-LCD , LCM |
| uqwalaselo | RGB Vertical Stripe |
| ulwandlalo mfiliba. | - |
| umlinganiselo wokuchasana | 1000:1 (Typ.) (TM) |
| ixesha lokuphendula | 25 (Typ.)(Tr+Td) |
| indlela yokusebenza | IPS Pro, Normally Black, Transmissive |
| umthombo wokukhanya | WLED , 10K hours |
| yenzelwe | Pad & Tablet |
| indawo yokuthintela | Without |
| HSD101PFW2-B00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW2-C00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW3-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW4-B01 | HannStar | 10.1 | 1024×600 |
| HSD101PUW1-A00 | HannStar | 10.1 | 1920×1200 |
| HSD101PWW1-A00 Rev.4 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-B00 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-F01 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-G10 | HannStar | 10.1 | 1280×800 |
| HSD101PWW2-A01 | HannStar | 10.1 | 1280×800 |
