| Inombolo yendawo | HSD090LFW1-B00 |
| Uphawu | HannStar |
| Ubungakanani | 9.0 |
| Isicelo | Automotive Display |
| Isigqibo | 1024×600 |
| Ukuqamba | a-Si TFT-LCD, LCM |
| Ukuqaqamba | |
| CR | 800:1 |
| Imibala | 262K/16.2M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| uphawu | HannStar |
| imodeli | HSD090LFW1-B00 |
| ubungakanani bediagonal | 9.0 inch |
| uhlobo | a-Si TFT-LCD, LCM |
| ifomathi ye-pixel | 1024(RGB)×600 [WSVGA] 132PPI |
| uqwalaselo | RGB Vertical Stripe |
| indawo esebenzayo | 196.608(H)×114.15(V) mm |
| ulwandlalo mfiliba. | 211.1(H)×126.5(V) ×6(D) mm |
| indawo ye-bezel | 200.01(H)×117.55(V) mm |
| unyango | Glare (Haze 0%) |
| ukukhanya | 450 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 800:1 (Typ.) (TM) |
| Jonga indlela | Symmetry |
| ixesha lokuphendula | 17/18 (Typ.)(Tr/Td) |
| i-engile yokujonga | 85/85/85/85 (Typ.)(CR≥10) |
| indlela yokusebenza | IPS Pro, Normally Black, Transmissive |
| umbala inkxaso | 262K/16.2M 50% NTSC |
| umthombo wokukhanya | WLED , 150K hours , W/O Driver |
| ubunzima | 230g (Typ.) |
| yenzelwe | Automotive Display |
| umgangatho wefreyimu | 60Hz |
| indawo yokuthintela | Without |
| uhlobo lojongano | LVDS (1 ch, 6/8-bit) , 40 pins FPC |
| ukunikezwa Amandla | 3.3/12.5/23/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| okusingqongileyo | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.9G (28.4 m/s²) |
