| Inombolo yendawo | FC0802C00-FHYYBH-91LE |
| Uphawu | Fordata |
| Ubungakanani | 1.1 |
| Isicelo | Instruments & Me |
| Isigqibo | 5×8 |
| Ukuqamba | LCM, STN-LCD |
| Ukuqaqamba | |
| CR | 10:1 |
| Imibala | Monochrome |
| Isibane ngasemva | YG-LED |
| Ujongano | 8-bit |
| umenzi | Fordata |
| igama lemodeli | FC0802C00-FHYYBH-91LE |
| ubungakanani besikrini | 1.1 inch |
| uhlobo lwesikrini | LCM, STN-LCD |
| inombolo char | 8 characters × 2 lines 7PPI |
| ifomathi ye-char | 5×8 dots |
| iphiko lokutshisela(mm) | 3.35×5.15 (H×V) |
| ubungakanani bezinhlamvu (mm) | 2.95×4.75 (H×V) |
| indawo esebenzayo(mm) | 26.4 × 9.9 (H×V) |
| Ulwandlalo(mm) | 40 × 35.4 × 13 (H×V×D) |
| indawo ye-bezel(mm) | 30.4 × 13.9 (H×V) |
| unyango | - |
| ukukhanya | - |
| umlinganiselo wokuchasana | 10 : 1 (Typ.) (TM) |
| i-engile yokujonga | - |
| impendulo | 150/150 (Typ.)(Tr/Td) ms |
| umbono omhle kwi | 6 o'clock |
| imo yomsebenzi | STN, Yellow/Green (Positive), Transflective |
| ubunzulu bombala | Monochrome |
| isibane esingasemva | YG-LED , 20K hours , No Driver |
| ubunzima | - |
| esetyenziselwa | Instruments & Meters |
| izinga lokuhlaziya | - |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | 8-bit parallel , Pad 16 pins |
| unikezelo lombane | 3.0V (Typ.) |
| max. amanqaku | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
