| Inombolo yendawo | C100HAT01.0 |
| Uphawu | AUO |
| Ubungakanani | 10.0 |
| Isicelo | Automotive Display |
| Isigqibo | 1560×700 |
| Ukuqamba | LCM, a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | |
| Imibala | 16.7M |
| Isibane ngasemva | WLED |
| Ujongano | |
| umenzi | AUO |
| igama lemodeli | C100HAT01.0 |
| ubungakanani besikrini | 10.0 inch |
| uhlobo lwesikrini | LCM, a-Si TFT-LCD |
| inombolo pixel | 1560(RGB)×700 171PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 231.66 × 103.95 (H×V) |
| Ulwandlalo(mm) | 259.36 × 131.32 (H×V×D) |
| indawo ye-bezel(mm) | - |
| unyango | Antiglare, Antireflection |
| i-engile yokujonga | 80/80/80/80 (Typ.)(CR≥10) |
| impendulo | 30 (Max.)(Tr+Td) ms |
| umbono omhle kwi | Symmetry |
| imo yomsebenzi | AHVA, Normally Black, Transmissive |
| ubunzulu bombala | 16.7M |
| isibane esingasemva | WLED |
| ubunzima | 375±38g |
| esetyenziselwa | Automotive Display |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | - |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
| ELT256.120.90 | Lumineq | 10.0 | 256×120 |
| HSD100PXN1-A00 | HannStar | 10.0 | 1024×768 |
| HSD100PXN1-A00-C11 | HannStar | 10.0 | 1024×768 |
| LM100SS1T522 | SHARP | 10.0 | 800×600 |
| PM100WX2 | E Ink | 10.0 | 800×480 |
| PW100XS1 | E Ink | 10.0 | 640×468 |
| PW100XS5 | E Ink | 10.0 | 640×468 |
| SVA101WV1(01TA)(A) | SVA-NEC | 10.0 | 1024×576 |
| TM100SV-A01-01 | SANYO | 10.0 | 800×600 |
| TM100SV-A02-01 | SANYO | 10.0 | 800×600 |
