SVA101WV1(01TA)(A)

SVA101WV1(01TA)(A)
SVA101WV1(01TA)(A)
SVA101WV1(01TA)(A)
SVA101WV1(01TA)(A) thumb SVA101WV1(01TA)(A) thumb SVA101WV1(01TA)(A) thumb
Uphawu
SVA-NEC
Ubungakanani
10.0
Isicelo
NOPC
Isigqibo
1024×576
Ukuqamba
LCM
Ukuqaqamba
200
CR
400:1
Imibala
262K
Isibane ngasemva
WLED
Ujongano
LVDS
In Stock
5422
Iinkcukacha

Inombolo yendawo SVA101WV1(01TA)(A)
UphawuSVA-NEC
Ubungakanani10.0
IsiceloNOPC
Isigqibo1024×576
UkuqambaLCM
Ukuqaqamba200
CR400:1
Imibala262K
Isibane ngasemvaWLED
UjonganoLVDS
uphawu lwephaneliSVA-NEC
imodeli yephaneliSVA101WV1(01TA)(A)
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli10.0 inch
isisombululo1024(RGB)×576 , WSVGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo221.184×124.416 mm
ulwandlalo235×143×5.2 mm
umphezuluAntiglare, Hard coating (3H)
ukuqaqamba200 cd/m² (Typ.)
umlinganiselo wokuchasana400:1 (Typ.)
bonisa imibala262K (6-bit), CIE193145%
ixesha lokuphendula8 (Typ.)(Tr+Td)
i-engile yokujonga45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibaneWLEDEmbedded (LED Driver)
ujongano lomqondisoLVDS (1 ch, 6-bit), 40 pins
igalelo lombane3.3V (Typ.)
isiceloNOPC
