Innolux BT140GW01 V.5 idatadata, iinkcukacha, izitokhwe, usetyenziso www.looklcd-xh.com
LookLCD LookLCD


BT140GW01 V.5

BT140GW01 V.5
BT140GW01 V.5
BT140GW01 V.5 thumb BT140GW01 V.5 thumb
Uphawu
Innolux
Ubungakanani
14.0
Isicelo
NBPC
Isigqibo
1366×768
Ukuqamba
LCM
Ukuqaqamba
200
CR
600:1
Imibala
262K
Isibane ngasemva
WLED
Ujongano
LVDS
In Stock
1542
Iinkcukacha

Inombolo yendawo BT140GW01 V.5
UphawuInnolux
Ubungakanani14.0
IsiceloNBPC
Isigqibo1366×768
UkuqambaLCM
Ukuqaqamba200
CR600:1
Imibala262K
Isibane ngasemvaWLED
UjonganoLVDS
uphawu lwephaneliCHIMEI INNOLUX
imodeli yephaneliBT140GW01 V.5 4 Compatible model
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli14.0 inch
isisombululo1366(RGB)×768 , WXGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo309.399×173.952 mm
ulwandlalo323.5×192×5.2 mm
isitayile semiloWedge (PCBA Bent, Depth ≥5.2mm)
umphezuluGlare (Haze 0%), Hard coating (3H)
ukuqaqamba200 cd/m² (Typ.)
umlinganiselo wokuchasana600:1 (Typ.)
bonisa imibala262K (6-bit), CIE193145%
ixesha lokuphendula8 (Typ.)(Tr+Td)
i-engile yokujonga40/40/15/30 (Min.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibaneWLEDEmbedded (LED Driver)
ujongano lomqondisoLVDS (1 ch, 6-bit), 40 pins
igalelo lombane3.3V (Typ.)
isiceloNBPC
Umzekelo woSapho
B140XTN03.1 AUO 14.0 1366×768
BT140GW01 V.0 Innolux 14.0 1366×768
BT140GW01 V.4 Innolux 14.0 1366×768
BT140GW01 V.5 Innolux 14.0 1366×768
BT140GW01 V.A Innolux 14.0 1366×768
BT140GW02 V.0 Innolux 14.0 1366×768
BT140GW02 V.2 Innolux 14.0 1366×768
BT140GW02 V.9 Innolux 14.0 1366×768
BT140GW03 V.2 Innolux 14.0 1366×768
LP140WF1-SPB1 LG Display 14.0 1920×1080
Imveliso eshushu
B156XTK01.0 AUO 15.6 1366×768
LP121WX3-TLC1 LG Display 12.1 1280×800
LP133WD1-SLA1 LG Display 13.3 1600×900
LP133WH2-SPA2 LG Display 13.3 1366×768
LP154WP2-TLA2 LG Display 15.4 1440×900
LP173WF1-TLA2 LG Display 17.3 1920×1080
LQ133T1JW19 SHARP 13.3 2560×1440
LTN156AT23-W01 Samsung 15.6 1366×768
N156B3-L0A Innolux 15.6 1366×768
N156B3-L0B Innolux 15.6 1366×768
