Inombolo yendawo | B154EW01 V4 |
Uphawu | AUO |
Ubungakanani | 15.4 |
Isicelo | NBPC |
Isigqibo | 1280×800 |
Ukuqamba | LCM |
Ukuqaqamba | 160 |
CR | 400:1 |
Imibala | 262K |
Isibane ngasemva | CCFL |
Ujongano | LVDS |
uphawu lwephaneli | AUO |
imodeli yephaneli | B154EW01 V4 |
uhlobo lwephaneli | a-Si TFT-LCD , LCM |
ubungakanani bephaneli | 15.4 inch |
isisombululo | 1280(RGB)×800 , WXGA |
imowudi yokubonisa | TN, Normally White, Transmissive |
indawo esebenzayo | 331.2×207 mm |
ulwandlalo | 344×222×6.5 mm |
isitayile semilo | Wedge (PCBA Bent, Depth ≥5.2mm) |
umphezulu | Antiglare, Hard coating (3H), Reflection 4.3% (Typ.) |
ukuqaqamba | 160 cd/m² (Typ.) |
umlinganiselo wokuchasana | 400:1 (Typ.) |
bonisa imibala | 262K (6-bit), CIE193152% |
ixesha lokuphendula | 4/12 (Typ.)(Tr/Td) |
i-engile yokujonga | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
rhoqo | 60Hz |
uhlobo lwesibane | 1 pcsCCFLEmbedded (Inverter) |
ujongano lomqondiso | LVDS (1 ch, 6-bit), 30 pins |
igalelo lombane | 3.3V (Typ.) |
isicelo | NBPC |
