B101AW01 V2 HW0A

B101AW01 V2 HW0A
B101AW01 V2 HW0A thumb
Uphawu
AUO
Ubungakanani
10.1
Isicelo
NOPC
Isigqibo
1024×576
Ukuqamba
LCM
Ukuqaqamba
200
CR
400:1
Imibala
262K
Isibane ngasemva
WLED
Ujongano
LVDS
In Stock
5
Iinkcukacha

Inombolo yendawo B101AW01 V2 HW0A
UphawuAUO
Ubungakanani10.1
IsiceloNOPC
Isigqibo1024×576
UkuqambaLCM
Ukuqaqamba200
CR400:1
Imibala262K
Isibane ngasemvaWLED
UjonganoLVDS
uphawu lwephaneliAUO
imodeli yephaneliB101AW01 V2 HW0A 5 Compatible model
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli10.1 inch
isisombululo1024(RGB)×576 , WSVGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo222.72×125.28 mm
ulwandlalo235×143×5.2 mm
isitayile semiloWedge (PCBA Bent, Depth ≥5.2mm)
umphezuluAntiglare, Hard coating (3H)
ukuqaqamba200 cd/m² (Typ.)
umlinganiselo wokuchasana400:1 (Typ.)
bonisa imibala262K (6-bit), CIE193145%
ixesha lokuphendula8 (Typ.)(Tr+Td)
i-engile yokujonga45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibaneWLEDEmbedded (LED Driver)
ujongano lomqondisoLVDS (1 ch, 6-bit), 40 pins
igalelo lombane3.3V (Typ.)
isiceloNOPC
Umzekelo woSapho
B101AW01 V0 HW5A AUO 10.1 1024×576
B101AW01 V2 HW0A AUO 10.1 1024×576
B101AW01 V2 HW5A AUO 10.1 1024×576
B101EAN01.6 AUO 10.1 1280×800
BP101WX1-300 BOE 10.1 1280×800
CLAA101ND07CW CPT 10.1 1024×600
DLC1010GIG Other 10.1 1280×800
HJ101IA-01F Innolux 10.1 1280×800
LP101WH1-TLB5 LG Display 10.1 1366×768
VVX10F034N00 Panasonic 10.1 1920×1200
Imveliso eshushu
B089AW01 V2 AUO 8.9 1024×600
B116XW01 V0 AUO 11.6 1366×768
B116XW05 V0 AUO 11.6 1366×768
HSD070PFW1-A00 HannStar 7.0 1024×600
LTN101NT02-B01 Samsung 10.1 1024×600
M101NWT4 R3 IVO 10.1 1024×600
N101L6-L0D Innolux 10.1 1024×600
N101N6-L02 Innolux 10.1 1024×576
N116BGE-L32 Innolux 11.6 1366×768
SVA101WV1(01TA)(A) SVA-NEC 10.0 1024×576
