AT080TN42 V.1

AT080TN42 V.1
AT080TN42 V.1
AT080TN42 V.1
AT080TN42 V.1 thumb AT080TN42 V.1 thumb AT080TN42 V.1 thumb
Uphawu
Innolux
Ubungakanani
8.0
Isicelo
CNS
Isigqibo
800×600
Ukuqamba
LCM
Ukuqaqamba
250
CR
500:1
Imibala
262K
Isibane ngasemva
WLED
Ujongano
TTL
In Stock
493
Iinkcukacha

Inombolo yendawo AT080TN42 V.1
UphawuInnolux
Ubungakanani8.0
IsiceloCNS
Isigqibo800×600
UkuqambaLCM
Ukuqaqamba250
CR500:1
Imibala262K
Isibane ngasemvaWLED
UjonganoTTL
uphawu lwephaneliINNOLUX
imodeli yephaneliAT080TN42 V.1
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli8.0 inch
isisombululo800(RGB)×600 , SVGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo162×121.5 mm
ulwandlalo183×141 mm
umphezuluAntiglare
ukuqaqamba250 cd/m² (Typ.)
umlinganiselo wokuchasana500:1 (Typ.)
bonisa imibala262K (6-bit)
ixesha lokuphendula10/15 (Typ.)(Tr/Td)
i-engile yokujonga70/70/50/70 (Typ.)(CR≥10)(L/R/U/D)
uhlobo lwesibane3S9PWLEDWithout Driver
ujongano lomqondisoParallel RGB (1 ch, 6-bit), 60 pins
igalelo lombane3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)
rohs:
isiceloCNS
Umzekelo woSapho
AT080TN01 Innolux 8.0 800×480
AT080TN03 V.1 Innolux 8.0 800×480
AT080TN03 V.2 Innolux 8.0 800×480
AT080TN03 V.7 Innolux 8.0 800×480
AT080TN42 Innolux 8.0 800×600
AT080TN42 V.1 Innolux 8.0 800×600
AT080TN43 Innolux 8.0 800×600
AT080TN52 Innolux 8.0 800×600
AT080TN52 V.1 Innolux 8.0 800×600
AT080TN64 Innolux 8.0 800×480
