AT050TN33 V.1

AT050TN33 V.1
AT050TN33 V.1
AT050TN33 V.1
AT050TN33 V.1 thumb AT050TN33 V.1 thumb AT050TN33 V.1 thumb
Uphawu
Innolux
Ubungakanani
5.0
Isicelo
PND
Isigqibo
480×272
Ukuqamba
LCM
Ukuqaqamba
350
CR
500:1
Imibala
16.7M
Isibane ngasemva
WLED
Ujongano
TTL
In Stock
1205
Iinkcukacha

Inombolo yendawo AT050TN33 V.1
UphawuInnolux
Ubungakanani5.0
IsiceloPND
Isigqibo480×272
UkuqambaLCM
Ukuqaqamba350
CR500:1
Imibala16.7M
Isibane ngasemvaWLED
UjonganoTTL
uphawu lwephaneliINNOLUX
imodeli yephaneliAT050TN33 V.1
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli5.0 inch
isisombululo480(RGB)×272 , WQVGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo110.88×62.832 mm
ulwandlalo120.7×75.8×3.3 mm
umphezuluAntiglare
ukuqaqamba350 cd/m² (Typ.)
umlinganiselo wokuchasana500:1 (Typ.)
bonisa imibala16.7M (8-bit), CIE193150%
ixesha lokuphendula10/15 (Typ.)(Tr/Td)
i-engile yokujonga70/70/50/70 (Typ.)(CR≥10)(L/R/U/D)
uhlobo lwesibane6S2PWLEDWithout Driver
ujongano lomqondisoParallel RGB (1 ch, 8-bit), 40 pins
igalelo lombane3.3V (Typ.)
isiceloPND
Umzekelo woSapho
AT050TN22 V.1 Innolux 5.0 640×480
AT050TN23 V.1 Innolux 5.0 640×480
AT050TN33 Innolux 5.0 480×272
AT050TN33 V.1 Innolux 5.0 480×272
AT050TN34 Innolux 5.0 480×272
AT050TN34 V.1 Innolux 5.0 480×272
AT050TN35 Innolux 5.0 480×272
AT050TN43 V.1 Innolux 5.0 800×480
H497TLB01.4 AUO 5.0 720×1280
LMS501KF03 Samsung 5.0 480×800
