| Inombolo yendawo | WG12232D-YYH-V |
| Uphawu | Winstar |
| Ubungakanani | 1.9 |
| Isicelo | Industrial Instrumen |
| Isigqibo | 122×32 |
| Ukuqamba | LCM , STN-LCD |
| Ukuqaqamba | |
| CR | 3:1 |
| Imibala | Monochrome |
| Isibane ngasemva | YG-LED |
| Ujongano | 8-bit |
| umenzi | Winstar |
| ubungakanani besikrini | 1.9 inch |
| inombolo pixel | 122×32 67PPI |
| indawo esebenzayo(mm) | 45.72 × 11.97 (H×V) |
| indawo ye-bezel(mm) | 52.0 × 15 (H×V) |
| ukukhanya | - |
| i-engile yokujonga | 30/30/20/40 (Typ.)(CR≥2) |
| umbono omhle kwi | 6 o'clock |
| ubunzulu bombala | Monochrome |
| ubunzima | - |
| izinga lokuhlaziya | - |
| uhlobo lomqondiso | 8-bit 6800 parallel , 18 pins Pad |
| unikezelo lombane | 5.0V (Typ.) |
| max. amanqaku | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| igama lemodeli | WG12232D-YYH-V |
| uhlobo lwesikrini | LCM , STN-LCD |
| ilungiselelo | Rectangle |
| Ulwandlalo(mm) | 59 × 29.3 × 5.5 (H×V×D) |
| unyango | - |
| umlinganiselo wokuchasana | 3 : 1 (Typ.) (TM) |
| impendulo | 100/100 (Typ.)(Tr/Td) ms |
| imo yomsebenzi | STN, Yellow/Green (Positive), Transflective |
| isibane esingasemva | YG-LED , 100K hours , With LED Driver |
| esetyenziselwa | Industrial Instruments & Meters |
| isikrini esibanjwayo | Without |
