Winstar WG12232A-TFH-V#A idatadata, iinkcukacha, izitokhwe, usetyenziso www.looklcd-xh.com
LookLCD LookLCD


WG12232A-TFH-V#A

WG12232A-TFH-V#A
WG12232A-TFH-V#A
WG12232A-TFH-V#A thumb WG12232A-TFH-V#A thumb
Uphawu
Winstar
Ubungakanani
2.2
Isicelo
Industrial Instrumen
Isigqibo
122×32
Ukuqamba
LCM ,   FSTN-LCD
Ukuqaqamba
CR
5:1
Imibala
Monochrome
Isibane ngasemva
WLED
Ujongano
8-bit
In Stock
17868
Iinkcukacha

Inombolo yendawo WG12232A-TFH-V#A
UphawuWinstar
Ubungakanani2.2
IsiceloIndustrial Instrumen
Isigqibo122×32
UkuqambaLCM ,   FSTN-LCD
Ukuqaqamba
CR5:1
ImibalaMonochrome
Isibane ngasemvaWLED
Ujongano8-bit
umenziWinstar
ubungakanani besikrini2.2 inch
inombolo pixel122×32   57PPI
indawo esebenzayo(mm)53.64 × 15.64 (H×V)
indawo ye-bezel(mm)60.0 × 18.0 (H×V)
ukukhanya-
i-engile yokujonga45/45/30/60 (Max.)(CR≥2)
umbono omhle kwi6 o'clock
ubunzulu bombalaMonochrome
ubunzima-
izinga lokuhlaziya-
uhlobo lomqondiso8-bit 6800 parallel , 20 pins Pad
unikezelo lombane3.0V (Typ.)
max. amanqakuStorage Temp.: -30 ~ 80 °C    Operating Temp.: -20 ~ 70 °C
igama lemodeliWG12232A-TFH-V#A
uhlobo lwesikriniLCM ,   FSTN-LCD
ilungiseleloRectangle
Ulwandlalo(mm)84 × 44 × 13.7 (H×V×D)
unyango-
umlinganiselo wokuchasana5 : 1 (Typ.) (TM)
impendulo150/150 (Typ.)(Tr/Td) ms
imo yomsebenziSTN, Black/White (Positive), Transflective
isibane esingasemvaWLED , 50K hours , No Driver
esetyenziselwaIndustrial Instruments & Meters
isikrini esibanjwayoWithout
Umzekelo woSapho
COM22H2P16ULC ORTUSTECH 2.2 240×320
CT022TN15 Innolux 2.2 176×220
DLC0220BMG Other 2.2 240×320
HGS128321-B-EH-LV Other 2.2 128×32
LH220Q32-FD01 LG Display 2.2 320×320
LMS220GF08 Samsung 2.2 240×320
LS022Q8UD04 SHARP 2.2 240×320
LTS220QC-F0J Samsung 2.2 176×220
SG12232A Other 2.2 122×32
TM022GDH11 Tianma 2.2 176×220
