| Inombolo yendawo | WEO001602GG |
| Uphawu | Winstar |
| Ubungakanani | 2.3 |
| Isicelo | Instruments & Me |
| Isigqibo | 16×27 |
| Ukuqamba | PM-OLED, OLED |
| Ukuqaqamba | |
| CR | 2000:1 |
| Imibala | Mono(Green) |
| Isibane ngasemva | self |
| Ujongano | 8-bit |
| uphawu lwephaneli | Winstar |
| imodeli yephaneli | WEO001602GG |
| ubungakanani bephaneli | 2.3" |
| uhlobo lwephaneli | PM-OLED, OLED |
| ifomati yokubonisa | 16 characters × 2 lines, 7PPI |
| ifomathi yefonti | 5×8 dots |
| ubungakanani bomlinganiswa | 2.97×5.57(W×H) mm |
| isandi somlinganiswa | 3.55×5.95(W×H) mm |
| indawo yokubonisa | 56.22(W)×11.52(H) mm |
| ukuvulwa kwe-bezel | 58.22(W)×13.52(H) mm |
| ubungakanani bamagqabantshintshi | 79(W)×44(H) ×9.67(D) mm |
| umphezulu | - |
| ukuqaqamba | - |
| umlinganiselo wokuchasana | 2000:1 (Typ.) (TM) |
| i-engile yokujonga | 88/88/88/88 |
| imowudi yokubonisa | - |
| eyona mbono kwi | Symmetry |
| ixesha lokuphendula | 0.01 (Typ.) |
| bonisa imibala | Mono(Green) |
| uhlobo lwesibane | self |
| rhoqo | - |
| isikrini esibanjwayo | Without |
| umqhubi ic | COGBuilt-in SSD1311M1Z |
| Ubunzima bephaneli | - |
| isicelo | Instruments & Meters |
| ujongano lomqondiso | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 16 pins Pad |
| igalelo lombane | 3.3/5.0V (Typ.)(VDD) |
