| Inombolo yendawo | WEG007616ABR |
| Uphawu | Winstar |
| Ubungakanani | 1.7 |
| Isicelo | Instruments & Me |
| Isigqibo | 76×16 |
| Ukuqamba | PM-OLED, OLED |
| Ukuqaqamba | |
| CR | |
| Imibala | Mono(Red) |
| Isibane ngasemva | self |
| Ujongano | CPU/SPI |
| uphawu | Winstar |
| imodeli | WEG007616ABR |
| ubungakanani bediagonal | 1.7 inch |
| uhlobo | PM-OLED, OLED |
| ifomathi ye-pixel | 76×16 45PPI |
| uqwalaselo | Rectangle |
| indawo esebenzayo | 41.7(H)×11.1(V) mm |
| ulwandlalo mfiliba. | 55.7(H)×32(V) ×11(D) mm |
| indawo ye-bezel | 46(H)×14.5(V) mm |
| unyango | - |
| Jonga indlela | Symmetry |
| ixesha lokuphendula | - |
| i-engile yokujonga | - |
| indlela yokusebenza | - |
| umbala inkxaso | Mono(Red) |
| umthombo wokukhanya | self |
| ubunzima | - |
| yenzelwe | Instruments & Meters |
| umgangatho wefreyimu | - |
| indawo yokuthintela | Without |
| d-ic iinkcukacha | COB Built-in WS0010 |
| uhlobo lojongano | CPU/SPI , 15 pins Pad |
| ukunikezwa Amandla | 5.0V (Typ.) |
| A017CN01 V1 | AUO | 1.7 | 480×240 |
| A017CN01 V2 | AUO | 1.7 | 480×240 |
| NVK16BSC001G-C-0000 | Neoview Kolon | 1.7 | 80×168 |
| TFT-GG1P0553UTSW-W-E | Other | 1.7 | 176×220 |
| UG-6028GDEBF02 | WiseChip | 1.7 | 160×128 |
