| Inombolo yendawo | WEA012864DLPP3N00003 |
| Uphawu | Winstar |
| Ubungakanani | 0.96 |
| Isicelo | Instruments & Meters |
| Isigqibo | 128×64 |
| Ukuqamba | OLED , PM-OLED |
| Ukuqaqamba | |
| CR | |
| Imibala | Mono(Yellow) |
| Isibane ngasemva | self |
| Ujongano | 4-wire |
| umenzi | Winstar |
| ubungakanani besikrini | 0.96 inch |
| inombolo pixel | 128×64 149PPI |
| indawo esebenzayo(mm) | 21.74 × 10.86 (H×V) |
| indawo ye-bezel(mm) | 23.94 × 12.06 (H×V) |
| i-engile yokujonga | - |
| umbono omhle kwi | Symmetry |
| ubunzulu bombala | Mono(Yellow) |
| ubunzima | - |
| izinga lokuhlaziya | - |
| umqhubi ic uluhlu | Built-in COG SSD1306BZ |
| uhlobo lomqondiso | 4-wire SPI, I²C , 8 pins PIN |
| unikezelo lombane | 3.3/5.0/7.5V (Typ.) |
| max. amanqaku | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 80 °C |
| igama lemodeli | WEA012864DLPP3N00003 |
| uhlobo lwesikrini | OLED , PM-OLED |
| ilungiselelo | Rectangle |
| Ulwandlalo(mm) | 38 × 28.5 × 4.37 (H×V×D) |
| unyango | - |
| impendulo | - |
| imo yomsebenzi | - |
| isibane esingasemva | self |
| esetyenziselwa | Instruments & Meters |
| isikrini esibanjwayo | Without |
| IROP018-010-0128064-W | Other | 0.96 | 128×64 |
| L3P10Y-81G00 | Epson | 0.96 | 1400×1050 |
| OEL9M0083-B-E | Other | 0.96 | 128×64 |
| OEL9M0083-R-E | Other | 0.96 | 128×64 |
| OEL9M0083-W-E | Other | 0.96 | 128×64 |
| OEL9M0083-Y-E | Other | 0.96 | 128×64 |
| RGS10096096WR001 | RiTdisplay | 0.96 | 96×96 |
| RGS10128064WR010 | RiTdisplay | 0.96 | 128×64 |
| UG-2864HLBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864HSWEG01 | WiseChip | 0.96 | 128×64 |
