| Inombolo yendawo | TM123XDHP90 |
| Uphawu | TIANMA |
| Ubungakanani | 12.3 |
| Isicelo | Industrial Outdoor H |
| Isigqibo | 1920×720 |
| Ukuqamba | a-Si TFT-LCD, LCM |
| Ukuqaqamba | |
| CR | 1000:1 |
| Imibala | 16.7M |
| Isibane ngasemva | 10S4P |
| Ujongano | LVDS |
| uphawu lwephaneli | TIANMA |
| imodeli yephaneli | TM123XDHP90 |
| ubungakanani bephaneli | 12.3" |
| uhlobo lwephaneli | a-Si TFT-LCD, LCM |
| isisombululo | 1920(RGB)×720, 166PPI |
| ifomathi ye-pixel | RGB Vertical Stripe |
| indawo yokubonisa | 292.32(W)×109.62(H) mm |
| ukuvulwa kwe-bezel | - |
| ubungakanani bamagqabantshintshi | 311(W)×130(H) ×15.7(D) mm |
| umphezulu | Antiglare (Haze 28%) |
| ukuqaqamba | 1000 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 1000:1 (Typ.) (TM) |
| i-engile yokujonga | - |
| imowudi yokubonisa | SFT, Normally Black, Transmissive |
| eyona mbono kwi | Symmetry |
| ixesha lokuphendula | 25 (Typ.)(Tr+Td) |
| bonisa imibala | 16.7M 98% sRGB |
| uhlobo lwesibane | 10S4P WLED , 10K hours , Without Driver |
| rhoqo | 60Hz |
| isikrini esibanjwayo | Without |
| Ubunzima bephaneli | 490g (Typ.) |
| isicelo | Industrial Outdoor High Brightness Automotive Display |
| ujongano lomqondiso | LVDS (2 ch, 8-bit) , 50 pins FPC |
| igalelo lombane | 3.3V (Typ.) |
| okusingqongileyo | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
