| Inombolo yendawo | TM121JDSG10 |
| Uphawu | TIANMA |
| Ubungakanani | 12.1 |
| Isicelo | Industrial |
| Isigqibo | 1280×800 |
| Ukuqamba | LCM , a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 1000:1 |
| Imibala | 16.7M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| umenzi | TIANMA |
| igama lemodeli | TM121JDSG10 |
| ubungakanani besikrini | 12.1 inch |
| uhlobo lwesikrini | LCM , a-Si TFT-LCD |
| inombolo pixel | 1280(RGB)×800 (WXGA) 124PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 261.12 × 163.2 (H×V) |
| Ulwandlalo(mm) | 278 × 184 × 10.4 (H×V×D) |
| indawo ye-bezel(mm) | 262.12 × 164.2 (H×V) |
| unyango | Antiglare |
| ukukhanya | 450 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 1000 : 1 (Typ.) (TM) |
| i-engile yokujonga | 85/85/85/85 (Typ.)(CR≥10) |
| impendulo | 12/13 (Typ.)(Tr/Td) ms |
| umbono omhle kwi | Symmetry |
| imo yomsebenzi | SFT, Normally Black, Transmissive |
| ubunzulu bombala | 16.7M 40% NTSC |
| isibane esingasemva | WLED , 50K hours , With LED Driver |
| ubunzima | 440g (Typ.) |
| esetyenziselwa | Industrial |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | LVDS (1 ch, 8-bit) , 30 pins Connector |
| unikezelo lombane | 3.3V (Typ.) |
| max. amanqaku | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
