| Inombolo yendawo | TM103XDKP38-00 |
| Uphawu | TIANMA |
| Ubungakanani | 10.3 |
| Isicelo | Outdoor High Brightn |
| Isigqibo | 1920×720 |
| Ukuqamba | LCM, a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 1000:1 |
| Imibala | 16.7M |
| Isibane ngasemva | 8S3P |
| Ujongano | LVDS |
| umenzi | TIANMA |
| igama lemodeli | TM103XDKP38-00 |
| ubungakanani besikrini | 10.3 inch |
| uhlobo lwesikrini | LCM, a-Si TFT-LCD |
| inombolo pixel | 1920(RGB)×720 200PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 243.648 × 91.368 (H×V) |
| Ulwandlalo(mm) | 261.04 × 109.3 (H×V×D) |
| indawo ye-bezel(mm) | - |
| unyango | Hard coating, Reflection 5.5% (Typ.) |
| ukukhanya | 800 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 1000 : 1 (Typ.) (TM) |
| i-engile yokujonga | 88/88/88/88 (Typ.)(CR≥10) |
| impendulo | 20 (Typ.)(Tr+Td) ms |
| umbono omhle kwi | Symmetry |
| imo yomsebenzi | SFT, Normally Black, Transmissive |
| ubunzulu bombala | 16.7M 74% NTSC |
| isibane esingasemva | 8S3P WLED , 10K hours , No Driver |
| ubunzima | TBD |
| esetyenziselwa | Outdoor High Brightness Automotive Display |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | LVDS (2 ch, 8-bit) , Connector 50 pins |
| unikezelo lombane | 3.3/3.3V (Typ.)(VDD/AVDD) |
| max. amanqaku | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
