| Inombolo yendawo | TM101JDHG33 |
| Uphawu | TIANMA |
| Ubungakanani | 10.1 |
| Isicelo | Industrial Medical I |
| Isigqibo | 1280×800 |
| Ukuqamba | a-Si TFT-LCD , LCM |
| Ukuqaqamba | |
| CR | 700:1 |
| Imibala | 262K/16.7M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| uphawu | TIANMA |
| ubungakanani bediagonal | 10.1 inch |
| ifomathi ye-pixel | 1280(RGB)×800 [WXGA] 149PPI |
| indawo esebenzayo | 216.96(H)×135.6(V) mm |
| indawo ye-bezel | 219.96(H)×138.6(V) mm |
| ukukhanya | 900 cd/m² (Typ.) |
| Jonga indlela | Symmetry |
| i-engile yokujonga | 85/85/85/85 (Typ.)(CR≥10) |
| umbala inkxaso | 262K/16.7M 50% NTSC |
| ubunzima | 280g (Typ.) |
| umgangatho wefreyimu | 60Hz |
| uhlobo lojongano | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| ukunikezwa Amandla | 3.3V (Typ.) |
| okusingqongileyo | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 80 °C |
| imodeli | TM101JDHG33 |
| uhlobo | a-Si TFT-LCD , LCM |
| uqwalaselo | RGB Vertical Stripe |
| ulwandlalo mfiliba. | 229.8(H)×149(V) ×9.6(D) mm |
| unyango | Hard coating |
| umlinganiselo wokuchasana | 700:1 (Typ.) (TM) |
| ixesha lokuphendula | 25 (Typ.)(Tr+Td) |
| indlela yokusebenza | SFT, Normally Black, Transmissive |
| umthombo wokukhanya | WLED , 40K hours , With LED Driver |
| yenzelwe | Industrial Medical Imaging Outdoor High Brightness |
| indawo yokuthintela | Without |
| B101AW02 V0 | AUO | 10.1 | 1024×600 |
| B101AW06 V1 HW0A | AUO | 10.1 | 1024×600 |
| CLAA101NB03A | CPT | 10.1 | 1024×600 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| LP101WH1-TLA2 | LG Display | 10.1 | 1366×768 |
| LTL101AL02-T01 | Samsung | 10.1 | 1280×800 |
| LTN101NT02-W05 | Samsung | 10.1 | 1024×600 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
| TM101DDHG03 | Tianma | 10.1 | 1024×600 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
