| Inombolo yendawo | TM097TDHG04-62 |
| Uphawu | TIANMA |
| Ubungakanani | 9.7 |
| Isicelo | Pad & Tablet Industr |
| Isigqibo | 1024×768 |
| Ukuqamba | a-Si TFT-LCD , LCM |
| Ukuqaqamba | |
| CR | 500:1 |
| Imibala | 262K |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| uphawu | TIANMA |
| ubungakanani bediagonal | 9.7 inch |
| ifomathi ye-pixel | 1024(RGB)×768 [XGA] 132PPI |
| indawo esebenzayo | 196.608(H)×147.456(V) mm |
| indawo ye-bezel | 200.91(H)×152.27(V) mm |
| ukukhanya | 350 cd/m² (Typ.) |
| Jonga indlela | 12 o'clock |
| i-engile yokujonga | 70/70/60/70 (Typ.)(CR≥10) |
| umbala inkxaso | 262K 50% NTSC |
| ubunzima | 200g (Typ.) |
| umgangatho wefreyimu | 60Hz |
| uhlobo lojongano | LVDS (1 ch, 6-bit) , 30 pins Connector |
| ukunikezwa Amandla | 3.3V (Typ.) |
| okusingqongileyo | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| imodeli | TM097TDHG04-62 |
| uhlobo | a-Si TFT-LCD , LCM |
| uqwalaselo | RGB Vertical Stripe |
| ulwandlalo mfiliba. | 210.2(H)×166.3(V) ×6.5(D) mm |
| unyango | Clear |
| umlinganiselo wokuchasana | 500:1 (Typ.) (TM) |
| ixesha lokuphendula | 20/25 (Typ./Max.)(Tr+Td) |
| indlela yokusebenza | TN, Normally White, Transmissive |
| umthombo wokukhanya | WLED [6S6P] , 30K hours , W/O Driver |
| yenzelwe | Pad & Tablet Industrial |
| indawo yokuthintela | Without |
