| Inombolo yendawo | TM097TDHG04-02 |
| Uphawu | TIANMA |
| Ubungakanani | 9.7 |
| Isicelo | Pad & Tablet Industr |
| Isigqibo | 1024×768 |
| Ukuqamba | a-Si TFT-LCD , LCM |
| Ukuqaqamba | |
| CR | 500:1 |
| Imibala | 262K |
| Isibane ngasemva | 6S6P |
| Ujongano | LVDS |
| uphawu lwephaneli | TIANMA |
| ubungakanani bephaneli | 9.7" |
| isisombululo | 1024(RGB)×768, XGA, 132PPI |
| indawo yokubonisa | 196.608(W)×147.456(H) mm |
| ubungakanani bamagqabantshintshi | 210.2(W)×166.3(H) ×5.85(D) mm |
| ukuqaqamba | 350 cd/m² (Typ.) |
| i-engile yokujonga | 70/70/60/70 (Typ.)(CR≥10) |
| eyona mbono kwi | 12 o'clock |
| bonisa imibala | 262K 50% NTSC |
| rhoqo | 60Hz |
| Ubunzima bephaneli | 200g (Typ.) |
| ujongano lomqondiso | LVDS (1 ch, 6-bit) , 30 pins Connector |
| igalelo lombane | 3.3V (Typ.) |
| okusingqongileyo | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| imodeli yephaneli | TM097TDHG04-02 |
| uhlobo lwephaneli | a-Si TFT-LCD , LCM |
| ifomathi ye-pixel | RGB Vertical Stripe |
| ukuvulwa kwe-bezel | 200.91(W)×152.27(H) mm |
| umphezulu | Clear |
| umlinganiselo wokuchasana | 500:1 (Typ.) (TM) |
| imowudi yokubonisa | TN, Normally White, Transmissive |
| ixesha lokuphendula | 20/25 (Typ./Max.)(Tr+Td) |
| uhlobo lwesibane | 6S6P WLED , 30K hours , Without Driver |
| isikrini esibanjwayo | Without |
| isicelo | Pad & Tablet Industrial |
