| Inombolo yendawo | TM070RDHP10-00 |
| Uphawu | TIANMA |
| Ubungakanani | 7.0 |
| Isicelo | Automotive Display |
| Isigqibo | 800×480 |
| Ukuqamba | a-Si TFT-LCD, LCM |
| Ukuqaqamba | |
| CR | 1000:1 |
| Imibala | 16.7M |
| Isibane ngasemva | WLED |
| Ujongano | Parallel |
| uphawu | TIANMA |
| imodeli | TM070RDHP10-00 |
| ubungakanani bediagonal | 7.0 inch |
| uhlobo | a-Si TFT-LCD, LCM |
| ifomathi ye-pixel | 800(RGB)×480 [WVGA] 133PPI |
| uqwalaselo | RGB Vertical Stripe |
| indawo esebenzayo | 152.4(H)×91.44(V) mm |
| ulwandlalo mfiliba. | 165.1(H)×108.44(V) ×13(D) mm |
| indawo ye-bezel | 155.4(H)×94.44(V) mm |
| unyango | Antiglare, Hard coating (3H) |
| ukukhanya | 1000 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 1000:1 (Typ.) (TM) |
| Jonga indlela | Symmetry |
| ixesha lokuphendula | 35 (Max.)(Tr+Td) |
| i-engile yokujonga | 88/88/88/88 (Typ.)(CR≥10) |
| indlela yokusebenza | SFT, Normally Black, Transmissive |
| umbala inkxaso | 16.7M 71% NTSC |
| umthombo wokukhanya | WLED [8S2P] , 10K hours , W/O Driver |
| ubunzima | 180g (Max.) |
| yenzelwe | Automotive Display |
| umgangatho wefreyimu | 60Hz |
| indawo yokuthintela | Without |
| uhlobo lojongano | Parallel RGB (1 ch, 6/8-bit) , 40 pins FPC |
| ukunikezwa Amandla | 3.3V (Typ.) |
| okusingqongileyo | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -45 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
