| Inombolo yendawo | TM070RDHG34 |
| Uphawu | TIANMA |
| Ubungakanani | 7.0 |
| Isicelo | Industrial Outdoor H |
| Isigqibo | 800×480 |
| Ukuqamba | LCM, a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 800:1 |
| Imibala | 16.7M |
| Isibane ngasemva | 3S8P |
| Ujongano | |
| umenzi | TIANMA |
| igama lemodeli | TM070RDHG34 |
| ubungakanani besikrini | 7.0 inch |
| uhlobo lwesikrini | LCM, a-Si TFT-LCD |
| inombolo pixel | 800(RGB)×480 (WVGA) 134PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 154.08 × 85.92 (H×V) |
| Ulwandlalo(mm) | 164.9 × 100 × 6 (H×V×D) |
| indawo ye-bezel(mm) | 157.08 × 89.39 (H×V) |
| unyango | Antiglare |
| ukukhanya | 1000 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 800 : 1 (Typ.) (TM) |
| i-engile yokujonga | 70/70/60/70 (Typ.)(CR≥10) |
| impendulo | 25 (Typ.)(Tr+Td) ms |
| umbono omhle kwi | 6 o'clock |
| imo yomsebenzi | TN, Normally White, Transmissive |
| ubunzulu bombala | 16.7M 50% NTSC |
| isibane esingasemva | 3S8P WLED , 50K hours , No Driver |
| ubunzima | TBD |
| esetyenziselwa | Industrial Outdoor High Brightness Automotive Display |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
| TM070DDH02 | Tianma | 7.0 | 1024×600 |
| TM070DDH03 | Tianma | 7.0 | 1024×600 |
| TM070DDH07 | Tianma | 7.0 | 1024×600 |
| TM070DDH09 | Tianma | 7.0 | 1024×600 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
