| Inombolo yendawo | TM057QDH01-41 |
| Uphawu | TIANMA |
| Ubungakanani | 5.7 |
| Isicelo | Industrial |
| Isigqibo | 640×480 |
| Ukuqamba | LCM, a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 500:1 |
| Imibala | 262K |
| Isibane ngasemva | 7S3P |
| Ujongano | Parallel |
| umenzi | TIANMA |
| igama lemodeli | TM057QDH01-41 |
| ubungakanani besikrini | 5.7 inch |
| uhlobo lwesikrini | LCM, a-Si TFT-LCD |
| inombolo pixel | 640(RGB)×480 (VGA) 141PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 115.2 × 86.4 (H×V) |
| Ulwandlalo(mm) | 144 × 104.6 × 12.8 (H×V×D) |
| indawo ye-bezel(mm) | 118.2 × 89.4 (H×V) |
| unyango | Antiglare, Hard coating (3H) |
| ukukhanya | 400 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 500 : 1 (Typ.) (TM) |
| i-engile yokujonga | 70/70/70/60 (Typ.)(CR≥10) |
| impendulo | 20 (Typ.)(Tr+Td) ms |
| umbono omhle kwi | 6 o'clock |
| imo yomsebenzi | TN, Normally White, Transmissive |
| ubunzulu bombala | 262K 50% NTSC |
| isibane esingasemva | 7S3P WLED , 50K hours , No Driver |
| ubunzima | 155g |
| esetyenziselwa | Industrial |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | Parallel RGB (1 ch, 6-bit) , Connector 33 pins |
| unikezelo lombane | 3.3V (Typ.) |
| max. amanqaku | Storage Temp.: -30 ~ 85 °C Operating Temp.: -20 ~ 70 °C |
