| Inombolo yendawo | TM028HDZG59 |
| Uphawu | TIANMA |
| Ubungakanani | 2.8 |
| Isicelo | Mobile Phone |
| Isigqibo | 240×320 |
| Ukuqamba | a-Si TFT-LCD , LCM |
| Ukuqaqamba | |
| CR | 400:1 |
| Imibala | 65K/262K |
| Isibane ngasemva | WLED |
| Ujongano | 16-bit |
| uphawu | TIANMA |
| ubungakanani bediagonal | 2.8 inch |
| ifomathi ye-pixel | 240(RGB)×320 [QVGA] 141PPI |
| indawo esebenzayo | 43.2(H)×57.6(V) mm |
| ukukhanya | 300 cd/m² (Typ.) |
| Jonga indlela | - |
| i-engile yokujonga | 70/70/70/58 (Typ.)(CR≥10) |
| umbala inkxaso | 65K/262K 63% NTSC |
| ubunzima | TBD |
| umgangatho wefreyimu | - |
| uhlobo lojongano | 16-bit 8080 parallel , 37 pins FPC |
| ukunikezwa Amandla | 2.7/3.3V (Min./Max.)(VCI/VCC1/VCC2) |
| okusingqongileyo | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| imodeli | TM028HDZG59 |
| uhlobo | a-Si TFT-LCD , LCM |
| uqwalaselo | RGB Vertical Stripe |
| ulwandlalo mfiliba. | 50(H)×69.2(V) mm |
| umlinganiselo wokuchasana | 400:1 (Typ.) (TM) |
| ixesha lokuphendula | 25 (Typ.)(Tr+Td) |
| indlela yokusebenza | TN, Normally White, Transmissive |
| umthombo wokukhanya | WLED [1S4P] , W/O Driver |
| yenzelwe | Mobile Phone |
| indawo yokuthintela | Without |
