| Inombolo yendawo | TCG085WVLCF-G00 |
| Uphawu | Kyocera |
| Ubungakanani | 8.5 |
| Isicelo | Industrial |
| Isigqibo | 800×480 |
| Ukuqamba | LCM , a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 500:1 |
| Imibala | 262K |
| Isibane ngasemva | WLED |
| Ujongano | Parallel |
| umenzi | Kyocera |
| igama lemodeli | TCG085WVLCF-G00 |
| ubungakanani besikrini | 8.5 inch |
| uhlobo lwesikrini | LCM , a-Si TFT-LCD |
| inombolo pixel | 800(RGB)×480 (WVGA) 109PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 184.8 × 110.88 (H×V) |
| Ulwandlalo(mm) | 210 × 134 × 11.1 (H×V×D) |
| indawo ye-bezel(mm) | - |
| unyango | Antiglare |
| ukukhanya | 320 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 500 : 1 (Typ.) (TM) |
| i-engile yokujonga | 60/60/60/45 (Typ.)(CR≥10) |
| impendulo | 15/35 (Typ.)(Tr/Td) ms |
| umbono omhle kwi | - |
| imo yomsebenzi | TN, Normally White, Transmissive |
| ubunzulu bombala | 262K 49% NTSC |
| isibane esingasemva | WLED , 50K hours , No Driver |
| ubunzima | TBD |
| esetyenziselwa | Industrial |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | 4-wire Resistive Touch, G/G |
| uhlobo lomqondiso | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| unikezelo lombane | 3.3V (Typ.) |
| max. amanqaku | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
